Products
Load cell
MODEL: FEATURES:
OCS-S135

Indicator 380
*.Wireless frequency: 433Mhz/2.4G
*.Kg/lb units
*.Handheld size: 220x105x50mm,LCD display 25mm height
*.Bi-directional transmission – 128 channel
*.Function:tare, zero, peak, filter setting, gravity setting,calibration. etc.
*.Battery: 4pcs AA size alkaline batteries, 50 hours radio continuous using.
*.Set-point used for safety and warning applications or for limit weighing.
*.RS-232 interface
*.AA battery 4pcs

OCS-SH135

Wireless indicator 580
*.Wireless frequency: 433Mhz/2.4G
*.Portable indicator with micro-printer
*.Leather bag include
*.LCD display with backlight
*.Microprinter to print date,time,serial no. commodity no. net weight and total weight
*.Company'name 16 digits input
*.Query on serial no. commodity no and date, then print weight and total weight
*.Store up to data records of 3000 weighings.
*.USB connection with PC
*.Software: live weighing value, input company name,complete storage ,print query and accumulation
*.3500mAh SC type NIMH batteries

OCS-SL135

Wireless indicator 180
*.Wireless frequency: 433Mhz/2.4G
*.Palm-sized housing, size:28*70*90mm
*.LCD display with backlight
*.Function: tare,zero,calibration and parameter setup
*.USB connection with PC
*.Software: live weighing value, input company name,complete storage ,print query and accumulation
*.USB power supply, lithium battery optional

OCS-SX135

OCS-SZ135

SPECIFICATIONS:

*. Weight accuracy: OIML III standard.
*. Continuous working: 100 hours(LCD);60 hours(LED)
*. Safe overload: 120%F.S.
*. Operating temp: - 10℃ ~ + 40℃
*. Operating humidity: <= 90%R.H.


Model Capacity Division N.W. (kg)
OCS-S135 1t 0.5kg 12
OCS-S135 2t 1kg 14
OCS-S135 3t 1kg 14
OCS-S135 5t 2kg 24
OCS-S135 10t 5kg 44
OCS-S135 20t 10kg 65

Model Capacity Division N.W. (kg)
OCS-SH135 1t 0.5kg 12
OCS-SH135 2t 1kg 14
OCS-SH135 3t 1kg 14
OCS-SH135 5t 2kg 24
OCS-SH135 10t 5kg 65
OCS-SH135 15t 5kg 65

Model Capacity Division N.W. (kg)
OCS-SL135 2t 1kg 11
OCS-SL135 3t 1kg 12
OCS-SL135 5t 2kg 18
OCS-SL135 10t 5kg 28
OCS-SL135 15t 5kg 50
OCS-SL135 20t 10kg 58

Model Max Cap Division N.W.(kg)
OCS-SX123 1t 0.5kg 15
OCS-SX123 2t 1kg 15
OCS-SX123 3t 1kg 15
OCS-SX123 5t 2kg 23
OCS-SX123 10t 5kg 45

Model Capacity Division N.W. (kg)
OCS-SZ135 30t 10kg 165
OCS-SZ135 50t 20kg 485
